cheapest ev jinma1003 Fast charging system 105ah Takeaway Box

The Ultimate Guide to the Cheapest EV Jinma1003: Fast Charging System and Key Features

The Jinma1003 stands out as one of the most affordable electric vehicles available today, combining efficiency, practicality, and modern technology in a compact design. With dimensions of 2360*1260*1700 mm, this vehicle is engineered to navigate urban landscapes with ease. Weighing in at a mere 360 kg, the Jinma1003 is lightweight yet robust, ensuring a stable and smooth driving experience. Despite its compact size, the vehicle can reach a maximum speed of 45 km/h, making it ideal for short commutes and city driving.

One of the key highlights of the Jinma1003 is its impressive range. With a maximum range of 130 km on a single charge, it offers a practical solution for daily travel needs. The vehicle is designed for single-person use, featuring a cargo box with dimensions of 532*1159*1050 mm. It boasts a rated load capacity of 220 kg, making it suitable for carrying essential items and small loads. The steering is managed via a middle handlebar, providing intuitive and responsive control.

Powering this efficient machine is a 3000W A/C motor coupled with a 105Ah LiFePO4 battery. The charging process is streamlined with a 220V intelligent charger, requiring only 2 to 3 hours to reach full capacity. This quick charging feature ensures minimal downtime and maximum productivity. Safety is paramount in the Jinma1003, as evidenced by its hydraulic disc brakes on both the front and rear, offering reliable stopping power.

The suspension system further enhances the driving experience, with a robust setup for both front and rear suspensions. The tires and wheel hubs are carefully selected to provide optimal grip and stability. Additionally, the Jinma1003 is equipped with a multifunctional multimedia system, including MP5, reverse camera, Bluetooth, and USB connector, ensuring connectivity and convenience on the go. The vehicle also features an electric heater, central locking system, and a one-button start feature, adding to its user-friendly and high-tech appeal.

Fast Charging System and Practical Applications of Jinma1003

The Jinma1003 is designed with a highly efficient fast charging system that significantly enhances its practicality for daily use. Equipped with a 220V intelligent charger, the vehicle can be fully charged within a span of just 2-3 hours. This rapid charging capability ensures that users can quickly recharge their vehicle during short breaks, making it ideal for continuous use throughout the day. The efficient charging system is particularly advantageous for short-distance travel and delivery purposes, minimizing downtime and maximizing productivity.

One of the standout features of the Jinma1003 is its suitability for takeaway delivery services. Its compact size allows for easy maneuvering through urban environments and congested traffic, while its decent cargo capacity ensures that it can handle a variety of delivery loads. The quick charging capability further enhances its appeal, enabling delivery drivers to maintain a steady workflow without extended periods of inactivity due to charging.

In addition to its practical charging system, the Jinma1003 is equipped with several convenience features that make it an excellent choice for urban use. The auto-level central lock provides enhanced security, while the one-button start feature adds a layer of user-friendly operation. The electric door is another practical feature, offering ease of access, especially useful during multiple stops and deliveries. These features collectively contribute to a seamless and efficient user experience.

Real-life scenarios illustrate the practical benefits of the Jinma1003. For instance, small business owners who require a reliable and economical vehicle for local deliveries will find the Jinma1003 to be an ideal solution. Delivery services, particularly those focused on food and small package deliveries, will benefit from the vehicle’s fast charging system and compact design. The Jinma1003 is not only cost-effective but also a practical and convenient option for those seeking the cheapest EV solution for urban mobility and delivery needs.

Specifications:

Item: jinma1003
L*W*H （mm): 2360*1260*1700
Curb Weight（kg）: 360
Max. Speed(km/h): 45
Max. Range (km): 130
Capacity (person): 1
Cargo Box/ Takeaway box: 532*1159*1050
Rated Load(kg): 220
Steering Mode: Middle Handlebar
A/C Motor: 3000W
Lithium Battery: 105Ah LiFePo4 Battery
Charging Time: 2-3 hrs (220V)
Charger: Intellengent Charger
Type: Hydraulic System
Front: Disc
Rear: Disc
Brake way: Handlebar brake
Front: Independent Double Wishbone
Rear: Integrated Rear Axle
Tyre: Front 120/70-R12 Rear145/70-R12
Wheel Hub: Aluminum Alloy Hub
Mutil-media: MP5+Reverse Camera,Plus Bluetooth,USB connector
Electric Heater: 60V 800W
Central Lock: Auto Level
One Button Start: Auto Level
Electric Door&Window: 2&2
Dashboard,LED light system: Head&rear light,Turn light,Brake light,Reverse light
LCD display: Voltmeter,power meter,kilometer
High and low speed switch: 1
Seats: Genuine Leather
Safety Belt: Front and rear safety belts
Sunvisor,Interior mirror: 2
Wiper: Electric
Mat: Carpet on whole vehicle
high and low speed switch ( for 3000w motor): 1

Jinma1003 Positioning:

The delivery solution for the last mile of the city. Cold chain, takeaway, express delivery, logistics and supermarket distribution, etc., it is the short-distance cargo transportation vehicle within the city.

3 wheels, 1 driver seat

Size: 2300x1260x1700mm

Size of cargo:580*1080*995mm

Curb weight:360kg

Loading capacity :200kg

Max.speed:45km/h

105Ah lithium battery Max distance 115km ,with fast charge system, full charge in 3 hours;

Options 206Ah lithium battery Max distance can reach 200km, with fast charge system, full charge in 6 hours.

Color: White&Silver Red&Silver Blue&Silver Grey&Black

Details of the vehicle：

1. ABS Resin Plastic Cover and painting

Whole cover with ABS Resin plastic , have excellent comprehensive physical, impact resistance ,Stability, two-thirds lighter weight than iron.

Automobile-grade,Robot-painting .

2. LED Light System

The integrate LED head &rear-light

Turn lights, brake lights, reverse lights. Low power consumption and increase 50% more in light transmittance.

3. Front Windshield

CCC certified tempered and laminated glass Improve visual and more safety.

4. Dashboard

LCD display, volt meter, power meter, kilometer and reverse camera,plus Bluetooth, MP5,USB connector.

5. Central lock and One button start

6. Electric Windows

7. Mat on the whole car

8. Optional Air Conditioner

9. Seat with belt

Genuine Leather with PU,optional rotating seat for easy getting on and off.

10. AC Motor (3000W)

AC motor with powerful and water proof, lower noise, no carbon brush, maintenance-free. Equipped with fast home charging system.

11. Lithium Iron Phosphate Battery

with BMS system, more than 2,500 times charging cycles(8-10 years) under working environment from -30 to 50 °C. Equipped with hill-start assist control.

Can be remote online monitoring. Automatic power off after full charge.

12. Electronic Control System

Use En-power electric control system , reliable and water-proof

13. Brake System

Front-disc Rear-drum,two-circuit hydraulic brake.

14. Suspension System

The front axle and suspension are independent suspensions, simple structure and excellent stability. The integrated rear axle,axle housing welded by seamless steel tube, lower noise,more durable and reliable.

15. Frame&Chassis

GB Standard Steel, under pickling，Photostatting and corrosion-resistant treatment

All kinds of Cargo Box for choose:

1) Cargo Box

Size:580*1080*995mm

It is a new type of inorganic environmental protection with high-performance , can be directly degraded in the environment after being discarded. With excellent properties such as electrical insulation, corrosion resistance and high temperature resistance.

2) Optional Cargo Box-Equip with cooling system and heating system.

Size:580*1080*995mm

Cooling system design for fruit,vegetable, seafood, drinks, medicine transportation, Adjustable refrigeration temperature from -18℃~10℃

Heating system design for takeaway , adjustable heating temperature from 40℃to 60 ℃. Cargo box can be divided to two space, one for cooling and one for heating.

Advantage

Save Cost

CKD (Completely Knocked Down) assembly reduce and save customs duty & transportation cost

Save time

Fast charger within 4-5 hours under home charger

Car sharing system

Customers can download the APP, scan the QR code on the vehicle, Users can pay the cost directly online .The company can manage all vehicles through the phones.
